FOCUSRITE Scarlett 18i20 4th Gen

FOCUSRITE Scarlett 18i20 4th Gen
FOCUSRITE Scarlett 18i20 4th Gen
Atlaide Jaunums -7%
FOCUSRITE Scarlett 18i20 4th Gen
FOCUSRITE Scarlett 18i20 4th Gen

Description

18i20 is the studio hub for engineers who need serious I/O. Whether you’re recording drums, a live session, or have plenty of hardware synths, you’ve got eight of our finest ultra-low-noise mic preamps, plus line, instrument, MIDI, S/PDIF, and expandability via ADAT connections. With 26 inputs and 26 outputs, you’re ready for whatever your session demands.






Key Features
  • Eight ultra-low-noise mic/line preamps
  • Two front-panel mic/line and instrument preamps
  • Two Air preamp modes for classic console sound
  • Clip Safe and Auto Gain modes
  • Ten line outputs inc. Alt speaker switching
  • Up to 16 channels of ADAT I/O
  • S/PDIF, MIDI, and Word Clock
  • Includes Hitmaker Expansion and DAW software bundle

Overview

  • Number of Microphone Preamps8
  • Phantom PowerYes (Independent)
  • Instrument Inputs2
  • Line Inputs8
  • Air ModeYes
  • Auto GainYes
  • Clip SafeYes
  • Line Outputs10
  • Headphone Outputs2
  • ADAT Inputs2 (16 channels at 44.1/48kHz and up to 8 channels at 96kHz)
  • ADAT Outputs2 (16 channels at 44.1/48kHz and up to 8 channels at 96kHz)
  • SPDIF Inputs1
  • SPDIF Outputs1
  • MIDI Inputs1
  • MIDI Outputs1
  • TalkbackYes
  • LoopbackYes
  • ConnectivityUSB Type-C
  • ProtocolUSB 2.0
  • Form FactorDesktop / Rack Mountable (1U)
  • Simultaneous I/O26 x 26
  • A/D Resolution24-bit/192 kHz
  • Bus PoweredNo

Dimensions

  • Height46.55mm
  • Width442mm
  • Depth259.73mm
  • Weight3.304kg

Supported sample rates

  • 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz

Microphone inputs

  • Frequency Response20-20kHz ± 0.06dB
  • Dynamic Range116dB (A-Weighted)
  • THD+N-100dB @ 8dB gain
  • Noise EIN-127dBu (A-Weighted)
  • Maximum Input Level16dBu
  • Gain Range69dB
  • Impedance3kΩ

Variable Line inputs

  • Frequency Response20-20kHz ± 0.05dB
  • Dynamic Range115.5dB (A-Weighted)
  • THD+N-100dB @ 8dB gain
  • Maximum Input Level22dBu
  • Gain Range69dB
  • Impedance24kΩ

Instrument inputs

  • Frequency Response20-20kHz ± 0.05dB
  • Dynamic Range113dB (A-Weighted)
  • THD+N-80dB @ 8dB gain
  • Maximum Input Level12dBu
  • Gain Range62dB
  • Impedance1MΩ

Line outputs (Balanced)

  • Frequency Response20-20kHz ± 0.02dB
  • Dynamic Range122dB (A-Weighted)
  • THD+N-112dB
  • Maximum Output Level16dBu
  • Impedance200Ω

Headphone outputs

  • Frequency Response20-20kHz ± 0.1dB @ 33Ω / 300Ω
  • Dynamic Range112dB @ 33Ω
    116dB @ 300Ω
  • THD+N-100dB @ 33Ω (Minimum)
    -110dB @ 300Ω (Minimum)
  • Maximum Output Level5dBu into 33Ω
    11dBu into 300Ω
  • Maximum Output Power57mW into 33Ω
    27mW into 300Ω
  • Impedance11Ω

Analogue to Digital Converter

  • THD+N-110dB
  • Dynamic Range120dB

Digital to Analogue Converter

  • THD+N-115dB
  • Dynamic Range130dB (A-Weighted)

Power

  • External30W

Compatibility

  • WindowsIntel, AMD, and Arm64 processors supported
  • macOSApple Silicon and Intel processors supported

What's in the box

  • Scarlett 18i20 audio interface
  • Rack Ears
  • 1.5m USB-C to USB-C cable
  • USB-C to USB-A adaptor
  • IEC power cable



Skaņas kartes
Bitu sistēma 24
Ekstras MIDI
Ieeju skaits 8 + 10
Izeju skaits 12 + 8
Pieslēguma veids USB C / ADAT
Veids Audio
