Name: DB TECHNOLOGIES OPERA 15
Brand: dB Technologies
Price: 519.00 EUR
Availability: InStock

DB TECHNOLOGIES OPERA 15

Pieejamība: IR VEIKALĀ
Ražotājs: dB Technologies
Modelis: 1030102490

0 atsauksmes - Uzrakstīt atsauksmi par produktu

519.00€

bez PVN: 428.93€

Daudzums

Pievienot grozam

Buy Now Ask a question

Pievienot vēlmju sarakstam Salīdzināt šo produktu

With the new OPERA series, dBTechnologies succeded once again in packing leading edge DSP processing, advanced design features and user friendliness in an unrivalled cabinet in its price range.

Exceptional power and a unique acoustic design combine in order to deliver a vigorous yet pristine sound, successfully adaptable to both playback and live music applications.

Opera’s asymmetrical horn has been completely redesigned in order to obtain both an asymetrical vertical dispersion and a double horizontal dispersion, ensuring an optimized throw pattern.

The system is equipped with a powerful Class D 600 W amplifier featuring advanced DSP processing where FIR filters allow the systems to deliver a coherent audio performance, uniform and crystal-clear from every listening position.

Technical Data

Speaker Type

2-Way Active Speaker

Acoustical data

Frequency Response [-10dB]

50 - 20.000 Hz

Frequency Response [- 3dB]

56 - 19.000 Hz

Max SPL

130 dB

1" Exit, 1.4 v.c.

Type HF

Compression driver

Horizontal Directivity

100° (85° up/120° down)

Vertical Directivity

85° (+ 25°/-60°)

Horn

Asymmetrical Horn

15", 2" v.c.

Amplifier

Amp Technology

Amp SMPS Power supply dual range

Amp Class

Class D

RMS Power

600 W

Peak Power

1200 W

Processor

Controller

DSP 56 bit

AD/DA Converter

24 bit/48 KHz

System Presets

Rotary Encoder (8 Presets)

X-Over Frequency

1800 Hz

Limiter

Peak, RMS, Thermal

Advanced DSP Functions

Linear Phase FIR Filters

Input

Signal Input

1xCombo (XLR/Jack 6.3 mm) MIC/Line
1xCombo (XLR/Jack 6.3 mm) MIC/Inst

Signal Output

1x XLR Male (CH1 Link/Mix OUT)
Selectable

Mechanics

Housing

Polypropylene with internal frame

Grille

Full grille

Handles

1 on left Side, 1 on Top

Rigging Points

2XM10 on Top + 1x M10 on Back

Pole Mount

D36 mm

Angles up

Monitor use 45°

Width

420 mm (16.54 in)

Height

722 mm (28.43 in)

Depth

419 mm (16.50 in)

Weight

18.3 kg (40.34 lbs)

Skandas un PA sistēmas
Frekvenču diapazons (Hz)	50 - 20.000
Jauda (RMS), W	600
Korpusa materiāls	Polipropelēns
Skaļruņa diametrs (collas)	15
Skaļums (max SPL), dB	130
Skaņas pārklājums	100° x 85°
Skandu ekstras	DSP / FIR filtrs
