Key Features
Electrical
• Line Voltage or Power over Ethernet (PoE) powered
• PoE 802.3af
• PoE Power: 15W
• Line Voltage or Power over Ethernet (PoE) powered
• PoE 802.3af
• PoE Power: 15W
Connections
• 2x Indoor Locking RJ45 Input & Output
• 8x 5pin XLR Input / Output
• 2x Indoor Locking RJ45 Input & Output
• 8x 5pin XLR Input / Output
Specification
- • ArtNet / sACN /DMX, 8 Port Node
- • Line Voltage or Power over Ethernet (PoE) powered
- • DHCP or Static IP Address
- • 1.7-inch LCD Display
- • Configurable from unit menu or web browser
- • DMX512
- • RDM
- • Artnet
- • sACN
- • 2x Indoor Locking RJ45 Input & Output
- • 8x 5pin XLR Input / Output
- • Length: 129.3mm
- • Width: 482.5mm
- • Height: 43.8mm
- • Weight: 2.16kg
- • AC Input 95-240V,50/60Hz
- • PoE 802.3af
- • AC Power: 15W
- • PoE Power: 15W
- • Power Consumption: 5.7W @ 120V and 5.9W @ 230V
- • Power Input Protection: Fuse, T1.25A/250V (5.2x20mm)
- • Ambient Operational Temperature: -20°C to 45°C
- • Humidity: <75%
- • Storage Temperature: 25°C
- • IP20
- • Indoor locking power cord
