IK MULTIMEDIA iKlip A/V

Specs

iKlip A/V Specifications

Holds any iPhone, iPod touch and Smartphone model with screens ranging in size from 3.5” to 6” with case on

Works with Digital Cameras, Field Recorders and devices compatible with standard UNC 1/4”-20 thread

Standard UNC 1/4”-20 thread mount

Frequency response: from 20 Hz to 20 kHz +/- 1.5dB

Noise: -98 dB fullband, phantom power ON

Maximum output level: 2 Vrms

Distortion: 0.025% THD

Phantom max current: 6mA

Battery duration (Alkaline AA): approx 60 hours when phantom is off, approx 20 hours when phantom is on

Material: Thermoplastic / Aluminum

Package includes

iKlip A/V

1/8” TRRS to 1/8” TRRS cable

Holding bracket

Wireless mic receiver and XLR cable are not included

Dimensions

Weight: 353g / 12.45oz

1/8” TRRS to 1/8” TRRS cable lenght: 20cm / 7.87”

Holding bracket width: 54mm (min) - 91mm (max) / 2.13” (min) - 3.58” (max)

Wireless mic receiver support size: 62mm x 31mm / 2.44” x 1.22”

Requirements

iOS Devices

Compatible with iPhone X*, iPhone 8 Plus*, iPhone 8*, iPhone 7 Plus*, iPhone 7*, iPhone SE, iPhone 6s Plus, iPhone 6s, iPhone 6 Plus, iPhone 6, iPhone 5s, iPhone 5c, iPhone 5, iPhone 4s, iPhone 4, iPhone 3GS, iPod touch (6th, 5th, 4th and 3rd generation). iOS 4.3 or later is required.

Android Devices

Compatible with any Smartphone model with screens ranging in size from 3.5” to 6” with case on. To be compatible, the mobile device must be compliant with the CTIA/AHJ wiring standard, which is illustrated as follows. As of today, all popular Android devices branded Samsung, LG, Motorola, Google Nexus, HTC, Huawei, Sony, Lenovo, Xiaomi and more, use this standard.
