MONACOR VMX-440/SW

MONACOR VMX-440/SW
MONACOR VMX-440/SW
MONACOR VMX-440/SW
MONACOR VMX-440/SW
VMX-440/SW
4-channel microphone line mixer
  • Mixing made easy! An easy-to-use operating concept and clearly arranged features. Two stereo line sources and two mono microphone sources can be mixed together without any problems. Each input channel features a tone control. The master output levels can be preadjusted via recessed trimming potentiometers in order to protect them against overload. An optional remote switch can mute the stereo master outputs.
  • 2 stereo line inputs
  • 2 balanced microphone inputs
  • Parallel stereo line input on the front panel
  • 3-way equalizer for each microphone input
  • Common 2-way tone control for the two line inputs
  • Muting via optional momentary push-button/switch
  • 2 adjustable stereo master outputs
  • Master output level can be preadjusted via trimming potentiometers
  • Adjustable headphone output
  • Stereo record output
  • 482 mm (19") rack installation, 1 RS, with supplied mounting brackets

Technical specifications VMX-440/SW
VMX-440/SW
  • No. of channels: 4
  • No. of inputs: 5
  • Mic input: 1 mV/600 Ω, 2 x 6.3 mm jack, bal.
  • Line input: 100 mV/10 kΩ, 3 x RCA L/R
  • Master output: 1-3 V/100 Ω, 2 x RCA L/R
  • Record output: 1 V/100 Ω, 1 x RCA L/R
  • Headphones: ≥ 32 Ω, 2 x 15 mW, 1 x 6.3 mm jack
  • Frequency range: 20-20,000 Hz
  • THD: 0.05%
  • S/N ratio: > 60 dB
  • Equalizer bass: ± 12 dB/30 Hz
  • Equalizer midrange: ± 12 dB/1 kHz (voice only)
  • Equalizer treble: ± 12 dB/12 kHz
  • Power supply: ˜ 230 V/50 Hz/10 VA
  • Mains voltage: ~ 230 V
  • Mains frequency: 50 Hz
  • Power consumption, operation: 10 VA
  • Admiss. ambient temp.: 0-40 °C
  • Width: 482 mm
  • Height: 45 mm
  • Depth: 180 mm
  • Rack spaces, RS: 1
  • Weight: 2.25 kg
CD atskaņotāji
Ekstras 2x mikrafonu ieejas
Funkcijas 2x stereo ieejas
Pastiprinātāji
Izeju skaits 2
Ieeju skaits 4
