SPH-225C
- High-end bass speaker, 120 W, 8 Ω
- High-rigidity cone
- Extra long excursion
- Small loss and low distortion
- For an impressive fundamental bass in any high-quality hi-fi combination and smaller subwoofers
- Also possible as a bass-midrange speaker in 2-way combinations
- Suitable for cabinets of extra small dimensions
Technical specifications SPH-225C
SPH-225C
- Impedance (Z): 8 Ω
- Frequency range: f3-3,000 Hz
- Resonant frequency (fs) 39 Hz
- Power rating (RMS): 120 W
- Peak music power output (MAX): 200 W
- Sensitivity: 90 dB/W/m
- Suspension compl. (Cms): 0.43 mm/N
- Moving mass (Mms): 36.6 g
- Mech. Q factor (Qms): 4.94
- Electr. Q factor (Qes): 0.31
- Total Q factor (Qts): 0.30
- Equivalent volume (Vas): 24 l
- DC resistance (Re): 5.9 Ω
- Force factor (BxL): 13.17 Tm
- Voice coil induct. (Le): 0.8 mH
- Voice coil diameter: Ø 50 mm
- Voice coil former: Kapton
- Linear excursion (XMAX): ± 6 mm
- Eff. cone area (Sd): 201 cm2
- Magnet weight: 1.1 kg
- Magnet diameter: Ø 140 mm
- Mounting cutout: Ø 181 mm
- Mounting depth: 97 mm
- Mounting hole diameter: Ø 209 mm
- Dimensions: Ø 222 mm x 102 mm
- Outside diameter: Ø 222 mm
- Width: Ø 222 mm
- Depth: 102 mm
- Admiss. ambient temp.: 0-40 °C
- Weight: 3.52 kg
- Packing unit: 1
- Type of speaker: 8"
Skaļruņi | |
Veids | Zemo frekvenču |
Peak jauda, W | 200 |
Pretestība, Ω | 8 |
RMS jauda, W | 120 |
Jūtība, dB | 90 |
